The modular equipment of the CLII series, is an excellent alternative for the works of great size like Hotels, Commercial Plazas, Industrial Warehouses, Hospitals, Office and Multipurpose Buildings, Commercial buildings, Industrial buildings, Hospitals, Office buildings, and multipurpose buildings.
These units can form tandem installations with modules of 30 Tons. up to a maximum of 300 Tons.
The flexibility of installation configuration allows to reduce the space required for its location inside the machine rooms.
Due to its great technology and use of the VRW system, it is a great option for the development of new projects and staggered investments.

Standard Configuration

  • Available cooling only
  • Modular capacity of 30 Tons. in 2 circuits (15 Tons.+15 Tons.)
  • Modular tandem configuration up to 300 Tons.
  • 2 independent cooling circuits
  • 2 fixed compressors
  • Yee-filter (Hydraulic circuit)
  • Operating voltage available 460 / 3 / 60
  • Display (Mother module)
  • Ball valve (Mother and son module)
  • Thermal dispersion water flow sensor
  • MODBUS communication language
  • R-410A refrigerant
  • ISO-9227 powder coating (1,500 hour salt spray test)
  • AHRI Certification
  • ETL Certification
  • Meets ASHRAE 90.1
  • Equipment eligible for LEED projects
  • High and low pressure switches
  • Thermal dispersion flow sensor in condensing and
    evaporating loop

Additional Comfiguration

  • Available in 208-230 / 3 / 60
  • Flood detection
  • High and low pressure transducers
  • Electronic isolation valves (In case of flooding)
  • BACnet communication (Ordered separately)

Measurements

FOOTPRINT
30 Tons
incm
Width32 5/16”82
Length59”149.9
Height75 5/8”192.1

Components
